• High quality imaging with 2 MP, 1920×1080 resolution
• 2.8 mm, 3.6 mm fixed focal lens
• Up to 25 m IR distance for bright night imaging
• Up to 20 m white light distance for bright night imaging
• One port for four switchable signals (TVI/AHD/CVI/CVBS）
• High quality audio with audio over coaxial cable, built-in mic
• Water and dust resistant (IP67)
• Smart-Hybrid light, optimize your security with flexible lighting options

Camera

Image Sensor2 MP CMOS

Max. Resolution1920 (H) × 1080 (V)

Min. Illumination0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR

Shutter TimePAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s

Day & NightICR

Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°

Signal SystemPAL/NTSC

Lens

Lens Type2.8 mm, 3.6 mm fixed focal lens

Focal Length & FOV

2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°

3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°

Lens MountM12

Microphone

Pickup DistanceIn a radius of up to 5 m

Amount1

Illuminator

Supplement Light TypeSmart, IR, White Light

Supplement Light Range

IR : Up to 25 m

White Light : Up to 20 m


Image SettingsBrightness, Sharpness, Smart IR

Frame Rate

TVI: 1080P @ 30 fps, 1080P @ 25 fps

AHD: 1080P @ 30 fps, 1080P @ 25 fps

CVI: 1080P @ 30 fps, 1080P @ 25 fps

CVBS: PAL/NTSC

Day/Night ModeAuto/Color

Wide Dynamic Range (WDR)Digital WDR

Image EnhancementDWDR/BLC/HLC/Global

White BalanceAuto/Manual

AGCYes

Interface

Video OutputSwitchable TVI/AHD/CVI/CVBS

General

MaterialPlastic

Dimension138.8 mm × 60.9 mm × 57.9 mm (5.47" × 2.4 " × 2.3")

WeightApprox. 155 g (0.34 lb.)

Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)

Communication

HIKVISION-C

Language

English

Power Supply

12 VDC ± 25%

*You are recommended to use one power adapter to supply the power for one camera.

ConsumptionMax. 3.3 W

Approval

ProtectionIP67
